Advanced Smart Solar Regulator for Off-Grid, Caravan & Marine Power Systems
Maximise Solar Efficiency with MPPT Technology
The Powerhouse 12/24V MPPT Solar Charge Controller (20A) delivers up to 20% more charging efficiency compared to traditional PWM regulators. Using Maximum Power Point Tracking (MPPT) circuitry, it intelligently optimizes voltage and current from your panels, ensuring you get the most energy from your solar array — perfect for new installations or boosting existing solar systems.
Designed for permanent solar setups using lead acid, gel, or lithium batteries, this compact controller automatically detects 12V or 24V systems and provides clear feedback through its LCD display and status LEDs. Ideal for caravans, off-grid cabins, pumping stations, marine systems, and remote lighting applications.
Key Features
Advanced MPPT Technology: Up to 20% higher charge energy than standard regulators
Multi-Chemistry Compatibility: Supports Sealed, Gel, Flooded Lead-Acid, LiFePO4, and Li(NiCoMn)O2 batteries
Automatic Voltage Detection: Auto-recognizes 12V/24V systems
High-Efficiency Tracking: Super-fast tracking with precision power conversion
Integrated LCD Display: Real-time status of charging, load, and battery health
Temperature Compensation: Adapts performance to environmental conditions
Comprehensive Protection: Built-in safeguards against overcharge, overload, and reverse polarity
Durable Construction: Compact, rugged housing rated to IP30 for reliability in harsh environments
Ideal For
Caravans, 4WDs & Camper Trailers
Off-Grid Solar Systems & Battery Banks
Marine Applications & Remote Installations
Pumping Stations, Electric Fences & Outdoor Lighting Systems
Technical Specifications
Rated Charge Current: 20A
System Voltage: 12V / 24V (auto recognized)
Voltage Range: 8V–32V
Max PV Open Circuit Voltage: 100V / 150V (optional)
Battery Types: Sealed, Gel, Flooded Lead-Acid, LiFePO4, Li(NiCoMn)O2
Equalized Charging Voltage: 14.6V (sealed), 14.8V (flooded)
Absorption Charging Voltage: 14.6V (sealed), 14.2V (GEL)
Float Charging Voltage: 13.8V
Low Voltage Reconnect (LVR): 12.6V
Low Voltage Disconnect (LVD): 10.8V
Static Loss: ≤45mA/12V, ≤37mA/24V
High Voltage Disconnect (HVD): 16V
Charging Duration: Absorption – 2 hrs | Equalization – 2 hrs
Operating Temperature: –20°C to +55°C
Protection Class: IP30
Grounding Type: Positive grounded
Dimensions: 174.5 × 145 × 50 mm
Weight: 0.525kg
Important Installation Note
Do not set up the controller using a common earth configuration. Both positive and negative leads from the battery, solar panel, and load must connect directly to the solar regulator as outlined in the user manual. Incorrect wiring may cause battery or load damage.
Why Choose the Powerhouse MPPT 20A Solar Controller?
The Powerhouse 12/24V 20A MPPT Controller combines cutting-edge solar tracking technology, multi-battery compatibility, and robust safety features in a single, easy-to-use unit. Whether you’re powering a caravan, 4WD setup, or off-grid cabin, it ensures maximum power output, battery protection, and long-term reliability.
