The UHF Wireless Microphone System With Handheld Mic 16 Ch is perfect for events, clubs, function centers, and more. This entry-level system provides 16 channels of interference-free operation and clear, crisp sound reproduction. It comes with a handheld microphone transmitter and outputs audio signal via XLR or 6.35mm jack. Front panel LED indicators show active antenna and audio levels. Enjoy hassle-free sound with this reliable system.
Features
16 Channels in 520 - 550MHz UHF Band
RF and AF signal presence LEDs
Tone squelch circuit for noise reduction
Range up to 70m in ideal conditions
6.35mm unbalanced line/mic output
3 pin balanced XLR mic output
Microphone transmitters require 2 x AA batteries (not included).
Note:
Requires 2 x AA batteries (sold separately)
Supplied complete with handheld transmitter microphone
Further Technical Info below:
Receiver
Carrier Frequency Range: 520-550MHz UHF band
Frequency Stability: ±0.005%
Oscillator: PLL Synthesised
Receiving Sensitivity: 10µV over 80dB S/N ratio
Image and Spurious Rejection: 80dB minimum
Selectivity: >50dB
Modulation Mode: FM
IF Frequency: 1st: 243.95MHz; 2nd: 10.7MHz
Tone Signal: 32.768kHz
S/N ratio: >94dB, at 48kHz deviation and 60dBµV antenna input
Audio Frequency Response: 50Hz to 15kHz (±3dB)
Total Harmonic Distortion: Less than 1.0% (at 1kHz)
Power Supply: 12V d.c.
Audio Output: Balanced and unbalanced outputs for Single channel / Switching diversity (Mic.=-20dB / Line = 0dB)
Current consumption: 130mA (max.)
Dimensions (mm) WxHxD: 170 x 32 x 106
Transmitters
Carrier Frequency Range: 520-550MHz UHF band
RF Power Output: 10mW (max.)
Oscillation Mode: PLL synthesized, 16 Channel selectable
Frequency Stability: ±0.005%
Maximum Deviation: ±48kHz with limiting compressor
Spurious Emission: >60dB below carrier frequency
Total Harmonic Distortion: <1% (at 1kHz)
Microphone Capsule: uni-directional electret condenser unit
Battery: 3V d.c. (2 x 1.5V AA size batteries ) or 2.4V d.c. ( 2 x 1.2V AA size rechargeable batteries)
Current consumption: 120mA +/- 5mA
Frequency Channel List
CH 1: 520.125MHz
CH 2: 520.825MHz
CH 3: 521.925MHz
CH 4: 525.025MHz
CH 5: 525.925MHz
CH 6: 528.525MHz
CH 7: 529.425MHz
CH 8: 532.325MHz
CH 9: 534.225MHz
CH 10: 535.625MHz
CH 11: 541.125MHz
CH 12: 543.225MHz
CH 13: 544.125MHz
CH 14: 544.825MHz
CH 15: 545.725MHz
CH 16: 549.525MHz
Suggested Channel Groupings
Use these channel selections when using multiple transmitters in the same area.
Group A: Channels 1, 2, 3, 6, 7, 9, 10, 16.
Group B: Channels 2, 5, 7, 8, 9, 10, 11, 14.
Group C: Channels 1, 3, 5, 7, 9, 10, 11, 13.
Group D: Channels 2, 4, 8, 10, 12, 14, 15, 16.
