Redback PA Amplifier Module 120 A1932A Made in Australia

Description

This module is suitable for emergency evacuation systems and operates using a 24V DC power source. It can receive a line level audio input and generate a 100V line output through a transformer. Additionally, it offers protection from short circuits, overload, and thermal cutouts, and is built with a steel chassis. With its focus on reliability and strong performance, this is the optimal audio power source for evacuation systems and other applications that require a DC-powered 100V line amplifier.

Features

  • Powered by nominal 24V DC
  • 100V line audio output
  • Line level audio input - 600mV
  • Short circuit, overload, and thermal cutout protection
  • Bolt-in chassis construction
  • Australian designed and assembled

      Specifications

      • Output Power: 120W RMS
      • Current Draw: 8A at full load, 220mA Quiescent
      • Freq. Response: 50Hz - 12kHz
      • Distortion: < 0.6%
      • Signal to Noise Ratio: -91dB
      • Sensitivity: 600mV RMS
      • Fuse Rating and Type: 7.5A M205
      • Dimensions: 210W x 170D x 87Hmm

      Product form

      This module is suitable for emergency evacuation systems and operates using a 24V DC power source. It can receive a... Read more

      SKU: AL-A1932A
      Barcode: 9321758241134

      4 in stock All Orders now shipped 6th January  Delivery times may vary based on your location and AU Post's service standards.

      $530.00 $520.00

        • Free shipping on all orders over $99*
        • 30 Day free no hassle returns - Even if you change your mind!
        • Secure Checkout Process! Shop with confidence!

        Description

        This module is suitable for emergency evacuation systems and operates using a 24V DC power source. It can receive a line level audio input and generate a 100V line output through a transformer. Additionally, it offers protection from short circuits, overload, and thermal cutouts, and is built with a steel chassis. With its focus on reliability and strong performance, this is the optimal audio power source for evacuation systems and other applications that require a DC-powered 100V line amplifier.

        Features

        • Powered by nominal 24V DC
        • 100V line audio output
        • Line level audio input - 600mV
        • Short circuit, overload, and thermal cutout protection
        • Bolt-in chassis construction
        • Australian designed and assembled

            Specifications

            • Output Power: 120W RMS
            • Current Draw: 8A at full load, 220mA Quiescent
            • Freq. Response: 50Hz - 12kHz
            • Distortion: < 0.6%
            • Signal to Noise Ratio: -91dB
            • Sensitivity: 600mV RMS
            • Fuse Rating and Type: 7.5A M205
            • Dimensions: 210W x 170D x 87Hmm
