Description
The Kemo M034N 40W Mono Amplifier Module is a compact, pre-built amplifier solution designed for DIY audio projects, custom installations, and embedded systems.
Engineered in Germany, this module is fully encapsulated in epoxy resin, providing exceptional durability, protection, and reliability. With a simple setup, just connect a DC power supply, speaker, and audio input—it offers a fast and cost-effective way to integrate amplification into your project.
Key Features
-
40W Maximum Output Power
Strong and reliable mono amplification for a wide range of applications
-
Wide Voltage Range (6–16V DC)
Flexible operation across various power supply configurations
-
Epoxy Encapsulated Design
Fully sealed module for enhanced durability and protection
-
High-Fidelity Audio Performance
Frequency response from 20Hz to 20kHz for clear, full-range sound
-
Simple Integration
Pre-built module with flying leads for quick installation
-
Compact Form Factor
Ideal for space-constrained or embedded applications
Important Installation Note
⚠️ This module must be mounted to a suitable heatsink for safe operation.
Recommended minimum heatsink size: approx. 100 x 40 x 20mm (or larger).
Applications
Perfect for:
- DIY audio amplifier projects
- Custom speaker builds
- Intercom and PA systems
- Automotive or portable audio setups
- Embedded audio solutions
Specifications
-
Brand: Kemo
-
Model: M034N
-
Amplifier Type: Mono
-
Max Power Output: 40W
-
Operating Voltage: 6–16V DC
-
Speaker Impedance: 4–8 Ohm
-
Frequency Response: 20Hz – 20kHz
-
Input Sensitivity: <500mV
-
Connections: 60mm flying leads
-
Encapsulation: Epoxy resin sealed
-
Dimensions: 70mm (W) × 45mm (D) × 29mm (H)
What’s Included
- 1 × Kemo M034N 40W Amplifier Module
Why Choose This Module?
The Kemo M034N offers a simple, reliable, and high-performance amplification solution for custom builds. Its robust construction and ease of integration make it ideal for both hobbyists and professionals looking for a dependable audio module.
