Digitech 0 to 30VDC 0 to 5A Regulated Power supply MP3840

Description

This professional lab power supply offers accurate voltage and current regulation, allowing you to configure precise levels to prevent overheating, burnout, and over-current. Its compact construction, featuring surface mount technology and efficient cooling, provides a highly flexible source. Output is adjustable up to 30VDC and 5A, and the 1mV ripple voltage guarantees precision. Output connections feature banana plug/binding posts and a bright LED display, and the unit is short-circuit protected. Includes a short banana to alligator lead set.

Features:

  • Precise voltage level and current limit settings
  • 1mV ripple voltage
  • Avoid overheating, burnout, and over-current
  • Easy-to-use LEDdisplay panel
  • Input voltage: 220-240AC 50-60Hz
  • Output voltage: 0-30VDC adjustable (10mV accuracy)
  • Output current: 0-5A adjustable (1mA accuracy)
  • Ripple current: 3mA

Specifications

  • AC Voltage rating: 230V
  • AC Frequency: 50Hz
  • DC current rating: 5A
  • DC Voltage: 30V
  • Length: 270mm
  • Width: 120mm
  • Height: 185mm
  • Weight: 4.8kg
  • Mains Voltage Range: 220V, 240V
  • Frequency: 50Hz
  • Rated for AU Mains: true
  • Rated for US Mains: false
  • Auto-select mains voltage: false
  • Mains Item connection: Standard IEC320 (C13/C14)
  • Mains lead included: true
  • Packaged Volume: 15.62l
  • Packaged Weight: 5.47kg
  • Packaged Length: 30.3cm
  • Packaged Width: 20.7cm
  • Packaged Height: 24.9cm
  • Type of Power Supply: Laboratory
  • Regulation Type: Regulated
  • Voltage Display: true
  • Current Display: true
  • Output Connection: Banana 4mm (standard)Binding Post Terminals
  • Number of Outputs: 1pc
  • Ripple Voltage: 1mV
