Description
BEHRINGER WAVES DIGITAL TIDAL MOD FUNCTION GENERATOR FOR EUROTRACK: Advanced Digital Modulation for Eurorack Systems
The BEHRINGER WAVES DIGITAL Generator for Eurorack is a versatile digital tidal modulator and function generator designed to bring precision and creativity to your Eurorack system. Based on the acclaimed Mutable Instruments Tides, this module provides three generator modes, enabling AD/AR envelopes, looping VC-LFO/VCDO, and advanced modulation capabilities. With its external clocking PLL and high-resolution CV control, it delivers exceptional accuracy and versatility for both studio and live performance setups.
Versatile Outputs and Customizable Control
This module features four output modes for generating various shapes, amplitudes, and frequencies. The shape control allows for fine-tuning the characteristics of waveforms, combining linear, exponential, or sinusoidal segments. Its semi-modular design supports extensive CV control, enabling deep integration into your modular setup. Whether you're creating harmonics, shaping rhythms, or exploring unique sonic textures, the WAVES module ensures unparalleled flexibility.
Key Features of the BEHRINGER WAVES DIGITAL TIDAL MOD FUNCTION Generator for Eurorack
- Digital tidal modulator and function generator for versatile modulation.
- Three generator modes: AD and AR envelopes with looping VC-LFO/VCDO.
- Four output modes: Generate a range of shapes, amplitudes, times, and frequencies.
- Shape control for linear, exponential, and sinusoidal segment combinations.
- External clocking PLL to create (sub)harmonics from other VCOs.
- High-resolution CV control for precision modulation with up to 16-bit resolution.
- Eurorack compatible: 14 HP with power consumption of 50 mA (+12 V) and 20 mA (-12 V).
Why Choose the BEHRINGER WAVES DIGITAL TIDAL MOD FUNCTION GEN?
The WAVES module combines the power of digital modulation with intuitive controls, ensuring exceptional versatility for sound design and rhythm creation. Whether you're an experimental sound artist or a traditional synthesist, this module offers the tools needed for innovative soundscapes and rhythmic textures. With its compact design and extensive connectivity, it's an ideal addition to any Eurorack setup.
Specifications
Inputs:
-
Slope CV: 3.5 mm TS jack, -8 V to +8 V range, impedance 50 kΩ
-
Frequency CV: 3.5 mm TS jack, -8 V to +8 V range, impedance 50 kΩ
-
V/Oct: 3.5 mm TS jack, -3 V to +5 V range, impedance 50 kΩ
-
Smoothness CV: 3.5 mm TS jack, -8 V to +8 V range, impedance 50 kΩ
-
Shape CV: 3.5 mm TS jack, -8 V to +8 V range, impedance 50 kΩ
-
Shift/Level CV: 3.5 mm TS jack, -8 V to +8 V range, impedance 50 kΩ
-
Trig: 3.5 mm TS jack, 5 V peak to peak, impedance 50 kΩ
-
Clock: 3.5 mm TS jack, 5 V peak to peak, impedance 50 kΩ
Outputs:
-
Outputs: 4 x 3.5 mm TS jack, DC coupled, impedance 1 kΩ
Power:
-
Consumption: 50 mA (+12 V) / 20 mA (-12 V)
Physical:
-
Dimensions: 129 x 71 x 41 mm (5.06 x 2.79 x 1.62")
-
Eurorack Size: 14 HP
-
Weight: 134.75 g (4.75 oz)
