BEHRINGER 1006 FILTAMP MODULE 🎛️🎶
Authentic 1970s Analog Sound in a Eurorack Format
The BEHRINGER 1006 FiltAmp Module is a faithful reproduction of the legendary "System 2500" circuitry from the 1970s, bringing vintage analog warmth into your Eurorack setup. Designed for both modular synth beginners and seasoned pros, the 1006 delivers rich, resonant filtering and a powerful voltage-controlled amplifier (VCA), making it a versatile and essential addition to any sound designer's toolkit.
Key Features:
✅ Authentic 1006 Analog Circuitry:
🎵 Faithfully recreates the classic "System 2500" sound.
✅ Classic 24 dB Transistor Ladder Filter:
🎚️ Warm low-pass filtering with vintage character.
✅ Powerful Voltage-Controlled Amplifier (VCA):
🔊 Adds rich depth and dynamics to your patches.
✅ Resonance Control:
🎛️ Adjustable resonance/peak response for precise sound shaping.
✅ Dual Audio Inputs:
🎼 Mix two audio sources with variable amplitude controls.
✅ Switchable VCA Response:
🔄 Choose between Exponential or Linear response for dynamic control.
✅ 1V/Oct Tracking:
🎯 Precise cutoff frequency modulation via external CV sources.
✅ Seamless Eurorack Integration:
🏗️ 16 HP width, fits standard Eurorack cases with low power draw.
Ideal For:
🎛️ Eurorack Builders – Adds classic vintage filtering & amplification.
🎹 Synth Enthusiasts – Achieve deep, resonant analog tones.
🎼 Sound Designers – Create expressive, evolving textures.
🎧 Electronic Music Producers – Perfect for subtractive synthesis & modulated tones.
Specifications:
🔹 Module Type: Analog Low-Pass Filter + VCA
🔹 Filter Type: 24 dB Transistor Ladder LPF
🔹 Power Requirements: 16 HP, +12V: 22 mA, -12V: 20 mA
🔹 VCA Mode: Exponential/Linear switchable
🔹 Cutoff Control: Manual & CV (1V/Oct)
🔹 Resonance: Adjustable peak response
🔹 Inputs: 2 x Audio Inputs
🔹 Dimensions: 5 cm (H) x 9.5 cm (W) x 15.4 cm (L)
🔹 Weight: 0.17 kg
Why Choose the BEHRINGER 1006 FILTAMP MODULE?
✔️ Faithful 1970s Analog Sound: Classic "System 2500" tones.
✔️ Dual Functionality: Low-pass filter + VCA in one compact module.
✔️ Rich Resonant Filtering: Deep, warm bass tones & screaming highs.
✔️ Flexible CV Control: Dynamic modulations with external sources.
✔️ Affordable Vintage Sound: Get legendary analog warmth without breaking the bank.
Expand your Eurorack with the BEHRINGER 1006 FILTAMP MODULE – The Ultimate Vintage Analog Filter & VCA!
