Redback 1 In to 2 Out Audio Splitter A4904

Description

This audio splitter, the Redback 1 In to 2 Out Audio Splitter A4904, features a compact design and multiple input/output configurations. With a 3 pin XLR input that can be set for 3mV or 1V sensitivity and an RCA auxiliary input that can be configured for 100mV or 1V sensitivity, this device provides two output sockets for each input. The input and output sensitivity can be easily adjusted using DIP switches, while dedicated volume controls allow for fine-tuning of each output. This splitter operates using a 24V dc external power source.
Dimensions: 112W x 45H x 55Dmm (excluding 12mm flanges).

This unit does not include a power supply. Requires 24V DC @ 500mA. Suitable plugpack M 8968C.

Features

  • 1 input to 2 outputs
  • Adjustable input and output signals
  • Individual volume controls for each output
  • Internally selectable phantom power available on XLR input
  • 24V dc operation
  • Compact design, 25H x 105W x 81D mm

Read more

Product form

$155.00

    ⏰ Order now, ships today!
    • Free shipping Australia-wide on orders over $99.
    • Secure checkout. Your payment is encrypted and protected.

    This audio splitter, the Redback 1 In to 2 Out Audio Splitter A4904, features a compact design and multiple input/output... Read more

    • Secure & safe checkout

      paypal
    American Express Apple Pay Google Pay Mastercard PayPal Shop Pay Visa
    🇦🇺 Aussie Owned 📦 44,000+ Products Sold

    Description

    This audio splitter, the Redback 1 In to 2 Out Audio Splitter A4904, features a compact design and multiple input/output configurations. With a 3 pin XLR input that can be set for 3mV or 1V sensitivity and an RCA auxiliary input that can be configured for 100mV or 1V sensitivity, this device provides two output sockets for each input. The input and output sensitivity can be easily adjusted using DIP switches, while dedicated volume controls allow for fine-tuning of each output. This splitter operates using a 24V dc external power source.
    Dimensions: 112W x 45H x 55Dmm (excluding 12mm flanges).

    This unit does not include a power supply. Requires 24V DC @ 500mA. Suitable plugpack M 8968C.

    Features

    • 1 input to 2 outputs
    • Adjustable input and output signals
    • Individual volume controls for each output
    • Internally selectable phantom power available on XLR input
    • 24V dc operation
    • Compact design, 25H x 105W x 81D mm

    Read more
