Mixers

Designed to cater to the increasing demands of PA systems with high power stereo amplifiers, this mixer boasts of 2 balanced microphone inputs (3 pin XLR) and 2 auxiliary inputs (stereo RCA & 3.5mm jack). Additionally, it includes balanced 3 pin XLR outputs for left and right channels, as well as standard stereo RCA outputs. Ideal for fitness centers, bars, bistros, and sporting clubs, it offers two sets of tone controls for both microphone and auxiliary inputs and a variable mute adjustment for the microphones. The master volume can be found on the rear panel.The Redback 4 Channel Stereo Mixer A4411 includes a "sub" output specifically designed for use with active subwoofers. This is perfect for gyms, clubs, and other venues. For added convenience, you can also connect a remote A4931 input plate, which will automatically mute auxiliary 1 and 2 when in use. Inputs: The rear panel of the mixer includes 3 pin balanced XLR sockets for each microphone input, capable of providing 15V DC phantom power. For input 1, there is also a front panel 6.35mm socket. Stereo auxiliary inputs can be connected using the dual RCA sockets. Additionally, there is a 3.5mm stereo jack socket on the front panel for auxiliary input 1, which can be used for connecting an MP3 player or similar device.Outputs: Left and right line level and 600Ω balanced outputs can be connected through the available RCA and XLR sockets. Additionally, the microphones feature a variable mute that can partially or fully mute the auxiliary inputs. Box Contents: A 4411 Four Channel Stereo Mixer 24V 1A DC Plugpack Instruction Booklet Features 2 microphone inputs Phantom power on MIc inputs (15V DC) 2 line inputs Separate tone controls for line and microphones Stereo outputs 1RU 19” rack mount case Master volume on rear panel Adjustable line muting Front panel mount microphone and line input Subwoofer output LED VU meter VOX active indicator Signal Present indicator 24V DC input 24V DC battery back up terminals 10 Year Warranty Australian designed & assembled Specifications Inputs Inputs: 2 x Mic balanced 600Ω, 2 x Line Stereo 10KΩ Outputs(stereo): 600Ω balanced 0dBm Distortion Mic inputs: less than 0.3% Line inputs: less than 0.3% Frequency Response Mic: 30Hz-15kHz Line: 20Hz-30kHz S/N ratio: -78dB Sensitivity: Mic 1.5mV, line 400mV Phantom power: Nominal 12V DC Output connectors: 3 pin XLR balanced Stereo RCA Input Connectors Mic: 3 pin XLR balanced rear panel, 6.35mm jack balanced front panel Line inputs: RCA stereo rear panel, 3.5mm stereo jack front panel Controls Mic inputs: Volume Line inputs: Volume Bass: ±12dB @ 100Hz Treble: ±12dB @ 10kHz Master Volume: On rear panel VOX sensitivity: On rear panel Mute level Aux 1 & 2: On rear panel Indicators: Power on LED Protection: 0.5A fuse Indicators: Power on, VOX active, Signal Present, VU Meter Power Supply: 24V DC Dimensions: 482W x 152D x 44H mm Weight: ≈2.2kg Colour: Black

Read more less

The Redback A5131 is equipped with 4 balanced mic inputs and 3 line inputs. Input 1 is designed for balanced mic use, while inputs 2 - 4 can handle both balanced mic and line level input. Microphones can be connected using a 5-way pluggable euro block, while line connections can be made through a stereo RCA socket (converted to mono internally). It also has two outputs, one for balanced output (selectable level of 3mV or 1V) and one for line level. The rear DIP switch allows for selection of 3 priority modes.Cascade: Input 1 overrides 2-4, Input 2 overrides 3-4, Input 3 overrides 4.FIBD: Regardless of which input is being used, it automatically blocks out all other inputs.None: No priority therefore all inputs will be mixed as per a normal mixer.Configuration options include PTT muting for microphone inputs and VOX muting for both microphone and line inputs. Each input has a volume control and channel active LED indicator. Features 4 balanced microphone / 3 line inputs 3 modes of priority Cascade, FIBD, None VOX or PTT muting VOX muting or both mic and line inputs Channel active indicators Stylish half width 1RU chassis 24V DC operation Separate volume for each input Adjustable VOX sensitivity for each input 24V DC plugpack included Includes Power Supply Rack Mounting:The H 4990 bracket is necessary for mounting any of the Redback half rack products onto a 19" wide racking system. Adding a metal (H 4992) or plastic (H 4993) infill panel to the H 4990 results in a more polished appearance when a single product is mounted.

Read more less

Expertly crafted to satisfy the needs of modern audio setups, this highly adaptable PA/BGM control system is the perfect solution for various venues such as clubs, pubs, and gyms. It serves as an ideal centralized controller for all audio inputs and outputs in a multi-zone setup, with a design that is both highly flexible and easily configured by the installer without the need for special training or programs.Optional accessories/features for the A4480B:Control zone and emergency paging with the A 4660 paging console. Adjust volume and music sources remotely with the A 4495 wall plate. Easily switch presets with the A 4476 preset wall plate. Connect a local microphone or music input with the A 4931 or A 4495 wall plates.Package Contents A 4480B Audio Switcher M 8973 24V 5A Power Supply 240V AC power lead (suits Australian Standard) USB - PS2 compatible keyboard (D 2111) Acrylic anti tamper cover Features 8 Stereo RCA line inputs (internally mono mixed). 2 Microphone XLR inputs with phantom power option. Adjustable line input sensitivity 0.3/0.7V. Individual bass, treble and volume controls of all line inputs. 8 Balanced 3 pin XLR line outputs. Individual volume controls of all 8 outputs. Alert/evacuation/pre chime tone generator included (alert/evac tones comply to AS1670.4) . Emergency balanced input with selectable phantom power and input sensitivity. Programmable labelling of input sources and output zones via USB keyboard. Programme isolate function. Four programmable presets. Tampering lockout feature. Power fail trigger. 240V AC or 24V DC operation. 19” Rack Mount (2 unit). Preset OperationThe Redback A4480B Audio Matrix Switcher features six user presets for easily recalling regularly used configurations. Presets one to four are programmable by the user and can be accessed at any time. Preset five serves as a convenient "last setting" option before a new preset is loaded, allowing for a quick return to a previous system configuration. Preset six serves as a backup of the initial system configuration. Users can select presets from the front panel or remotely by using the A 4476 preset selection wallplate.Input and Output OperationThis system can support 8 zone paging consoles, 8 local zone inputs, 1 emergency paging input, 1 alert/evac input, and 8 auxiliary audio source inputs. Each auxiliary input has a selectable sensitivity range of 0.3 to 0.7V and can be routed to any individual zone or combination of zones. Additionally, each input is equipped with volume, treble, and bass controls, as well as a signal presence indicator. The programmable display clearly shows the selected input and its corresponding outputs.The A4475 wallplate allows for remote selection of auxiliary inputs in each zone (maximum one per zone) when connected via Cat 5 cable. This wallplate allows for selecting any auxiliary source and adjusting the local level.A 4478 local input wallplate can be added to each zone for connecting local mic or line audio sources. This wallplate is compatible with the A 4475 program selection wallplate.Specialized volume controls and signal indicators ensure tamper-proof operation for emergency paging and alert/evac signals. Closing contacts initiate the alert/evac signal.Each output is equipped with volume controls and features 3-pin balanced line level XLRs, totaling 8 outputs.Program IsolateThis feature enables the "blocking" of chosen RCA audio inputs to designated zones. This has no impact on paging or tones.Priority Muting OperationThe Redback A4480B is a high-quality audio matrix switcher made in Australia, designed to efficiently handle 8 inputs and 8 outputs. With its priority muting system, this device ensures that appropriate signals are routed to designated zones based on the condition of the system. For instance, in an emergency paging mode, all inputs, including alert and evacuation signals, are muted to allow for live announcements through the paging microphone. In alert/evac mode, all inputs are muted, allowing for tones and recorded messages to be played throughout all zones. This functionality makes the A4480B a reliable choice for any professional audio setup. In the zone paging mode, auxiliary signals will be muted when a local input is connected through the optional A4478 wallplate. This prevents interruptions during functions or events and can be prohibited via the front panel's PA on/off function.

Read more less

Offering an enhanced PA mixing experience, the A4427 combines 8 audio channels with an MP3 tone generator, perfect for alert signals, chimes, and pre-recorded voice over messages. Select between 6 balanced mic or line inputs, utilizing stereo RCA or pluggable screw terminals. Additionally, enjoy two dedicated RCA inputs and a convenient 3.5mm jack input on the front panel for connecting local audio devices.Tone Generator Operation.This mixer allows for the playback of tones, chimes, and pre-recorded messages from a micro SD card that connects to the rear panel. Individual level controls are included for alert/evac, chime, and voice over, all of which can be activated through the closure of contacts, such as switches, from Fire Indicator Boards (FIB), or other remote contact sources..Adjustable Input Sensitivities.The DIP switch located on the rear panel enables users to choose between three different input sensitivities (3mV, 100mV, and 1V), as well as providing options for phantom power and VOX muting for each input.PowerThis mixer is equipped with a 24V DC power supply, including a 2.1mm DC jack input and a back up 24V DC power source through a screw terminal block in case of mains power failure. The 24V DC output is limited to 120mA current draw and is triggered by the Alert, Evacuation, or Chime functions, as well as VOX circuits or PTT muting.Box Contents A 4427 Mixer 8 Channel with MP3 active indicator 24V 1A DC Plugpack Instruction Booklet Features Eight input channels Micro SD card message player for audio announcements Individual level, bass and treble control on all inputs Six levels of VOX priority Adjustable VOX sensitivity 3.5mm music input Adjustable input sensitivity on line inputs 24V DC battery back up terminals In built Alert/Evac/Chime functionality 24V DC output MP3 active indicator LED VU meter 10 Year Warranty Australian Designed and Manufactured

Read more less

The Behringer PMP4000 Powered Mixer offers 1600W of output power and 16 channels for superior sound quality. Featuring built-in effects and 9-band graphic EQ, you'll achieve the perfect mix every time. Ideal for professional sound reinforcement, it's a reliable and powerful audio solution. The Behringer PMP4000 Powered Mixer ensures studio-quality sound with its 1600W output power and 16 channels for each mix. You'll have total control thanks to its built-in effects and 9-band graphic EQ that will make your sound come alive. And with its robust design and durability, you can rely on this mixer for professional sound reinforcement.

Read more less

This BEHRINGER XENYX QX1222USB MIXER provides professional-quality sound with 16-Input and 2/2-Bus Mixer. Featuring an ultra-low noise design, premium preamps and ultra-high headroom, this preamp offers sound quality and flexibility for any recording or live sound situation.

Read more less

  The X-DANTE card's 32-channel 48 kHz bi-directional audio interface expands I/O options, allowing X32 users and integrators to interface with Dante enabled IP networks. It easily installs in place of the X-USB card included with the X32, and features 24-bit signal transmission and sample-accurate synchronization for high audio integrity. Supports DSCP-based QoS and mixed sample and bit rate on the same network, plus a secondary input for a seamless, redundant network. Expansion slot provides flexible and expandable connectivity, and it's an economical way to connect I/O options in the network, eliminating physical wired links. The X-DANTE card - expanding X32's connectivity options.   BEHRINGER X-DANTE Expansion Card Networked Audio Solution Ultra-Low Latency High-Quality Audio Transmission Dante Network Integration Live Sound Application Broadcast Audio Solution Recording Studio Connectivity Flexible Routing Options Advanced Control Features

Read more less

The BEHRINGER X-ADAT DIGITAL MIXER OPTION is a professional piece of digital audio equipment designed to enhance the sound capabilities of your BEHRINGER X32 X-ADAT. It features 8 XLR inputs and 8 XLR outputs for a total of 16 channels, so you can create flawless soundscapes. This mixer option will give you the highest quality audio in your audio production endeavors. Create a 32 channel ADAT and clock expansion with the Behringer 32-Ch ADAT/Clock Expansion Card for X32 X-ADAT. This expansion card adds 32 additional channels of digital audio to your existing X32 system for maximum versatility. Professional audio engineers who have used this card have stated it is “incredibly useful” and “an essential accessory”.

Read more less

BEHRINGER XENYX 302USB: Ultra-Compact USB Mixer for Portable and Studio Use Looking for a compact, versatile mixer for your boardroom, home studio, or on-the-go recording needs? The XENYX 302USB is the perfect solution, designed for small home studios, podcasting, and quick recording sessions. With its state-of-the-art XENYX Mic Preamp, versatile input options, and stereo USB/Line channel, it’s ideal for both beginners and recording enthusiasts alike. Powered directly through your laptop's USB socket or with the included external power adaptor, the XENYX 302USB is the ultimate portable mixing solution. It also comes with recording and editing software, transforming your computer into a high-performance recording studio with ease. Key Features of the XENYX 302USB Ultra-Compact Design: Lightweight and easy to transport, perfect for on-the-go use or small home studios. USB/Audio Interface: Built-in stereo USB interface allows for direct connection to your computer, eliminating the need for additional hardware. XENYX Mic Preamp: Includes a phantom-powered XENYX Mic Preamp, offering sound quality comparable to stand-alone boutique preamps. Neo-Classic "British" 2-Band EQ: Adds a warm, musical sound to your recordings with this classic 2-band graphic EQ. Versatile Output Options: Includes Main Mix plus a separate Phones output for flexibility during recording sessions. Portable Power: Powered via USB or with the included external power adaptor, making it a truly portable option. 2-Track Input: Easily assignable to Headphone or Main Mix output for versatile monitoring. Dimensions of the XENYX 302USB Height: 4.6 cm Width: 11.4 cm Depth: 13.6 cm Weight: 0.38 kg Why Choose the XENYX 302USB? The XENYX 302USB is the ideal choice for podcasters, small recording studios, or those looking for a compact mixer that’s portable and easy to use. Its high-quality preamps, versatile input options, and USB connectivity make it perfect for quick setups and efficient recordings on the go.

Read more less
