Redback 8 Input To 8 Output Audio Matrix Switcher A4480B Made in Australia

Description

Expertly crafted to satisfy the needs of modern audio setups, this highly adaptable PA/BGM control system is the perfect solution for various venues such as clubs, pubs, and gyms. It serves as an ideal centralized controller for all audio inputs and outputs in a multi-zone setup, with a design that is both highly flexible and easily configured by the installer without the need for special training or programs.

Optional accessories/features for the A4480B:
Control zone and emergency paging with the A 4660 paging console. Adjust volume and music sources remotely with the A 4495 wall plate. Easily switch presets with the A 4476 preset wall plate. Connect a local microphone or music input with the A 4931 or A 4495 wall plates.

Package Contents

  • A 4480B Audio Switcher
  • M 8973 24V 5A Power Supply
  • 240V AC power lead (suits Australian Standard)
  • USB - PS2 compatible keyboard (D 2111)
  • Acrylic anti tamper cover

Features

  • 8 Stereo RCA line inputs (internally mono mixed).
  • 2 Microphone XLR inputs with phantom power option.
  • Adjustable line input sensitivity 0.3/0.7V.
  • Individual bass, treble and volume controls of all line inputs.
  • 8 Balanced 3 pin XLR line outputs.
  • Individual volume controls of all 8 outputs.
  • Alert/evacuation/pre chime tone generator included (alert/evac tones comply to AS1670.4) .
  • Emergency balanced input with selectable phantom power and input sensitivity.
  • Programmable labelling of input sources and output zones via USB keyboard.
  • Programme isolate function.
  • Four programmable presets.
  • Tampering lockout feature.
  • Power fail trigger.
  • 240V AC or 24V DC operation.
  • 19” Rack Mount (2 unit).

Preset Operation
The Redback A4480B Audio Matrix Switcher features six user presets for easily recalling regularly used configurations. Presets one to four are programmable by the user and can be accessed at any time. Preset five serves as a convenient "last setting" option before a new preset is loaded, allowing for a quick return to a previous system configuration. Preset six serves as a backup of the initial system configuration. Users can select presets from the front panel or remotely by using the A 4476 preset selection wallplate.

Input and Output Operation
This system can support 8 zone paging consoles, 8 local zone inputs, 1 emergency paging input, 1 alert/evac input, and 8 auxiliary audio source inputs. Each auxiliary input has a selectable sensitivity range of 0.3 to 0.7V and can be routed to any individual zone or combination of zones. Additionally, each input is equipped with volume, treble, and bass controls, as well as a signal presence indicator. The programmable display clearly shows the selected input and its corresponding outputs.

The A4475 wallplate allows for remote selection of auxiliary inputs in each zone (maximum one per zone) when connected via Cat 5 cable. This wallplate allows for selecting any auxiliary source and adjusting the local level.

A 4478 local input wallplate can be added to each zone for connecting local mic or line audio sources. This wallplate is compatible with the A 4475 program selection wallplate.

Specialized volume controls and signal indicators ensure tamper-proof operation for emergency paging and alert/evac signals. Closing contacts initiate the alert/evac signal.

Each output is equipped with volume controls and features 3-pin balanced line level XLRs, totaling 8 outputs.

Program Isolate
This feature enables the "blocking" of chosen RCA audio inputs to designated zones. This has no impact on paging or tones.

Priority Muting Operation
The Redback A4480B is a high-quality audio matrix switcher made in Australia, designed to efficiently handle 8 inputs and 8 outputs. With its priority muting system, this device ensures that appropriate signals are routed to designated zones based on the condition of the system. For instance, in an emergency paging mode, all inputs, including alert and evacuation signals, are muted to allow for live announcements through the paging microphone. In alert/evac mode, all inputs are muted, allowing for tones and recorded messages to be played throughout all zones. This functionality makes the A4480B a reliable choice for any professional audio setup.

In the zone paging mode, auxiliary signals will be muted when a local input is connected through the optional A4478 wallplate. This prevents interruptions during functions or events and can be prohibited via the front panel's PA on/off function.



Product form

Expertly crafted to satisfy the needs of modern audio setups, this highly adaptable PA/BGM control system is the perfect solution... Read more

SKU: AL-A4480B
Barcode: 9321758235324

5 in stock All Orders now shipped 6th January  Delivery times may vary based on your location and AU Post's service standards.

$3,000.00 $2,899.00

    • Free shipping on all orders over $99*
    • 30 Day free no hassle returns - Even if you change your mind!
    • Secure Checkout Process! Shop with confidence!

    Description

    Expertly crafted to satisfy the needs of modern audio setups, this highly adaptable PA/BGM control system is the perfect solution for various venues such as clubs, pubs, and gyms. It serves as an ideal centralized controller for all audio inputs and outputs in a multi-zone setup, with a design that is both highly flexible and easily configured by the installer without the need for special training or programs.

    Optional accessories/features for the A4480B:
    Control zone and emergency paging with the A 4660 paging console. Adjust volume and music sources remotely with the A 4495 wall plate. Easily switch presets with the A 4476 preset wall plate. Connect a local microphone or music input with the A 4931 or A 4495 wall plates.

    Package Contents

    • A 4480B Audio Switcher
    • M 8973 24V 5A Power Supply
    • 240V AC power lead (suits Australian Standard)
    • USB - PS2 compatible keyboard (D 2111)
    • Acrylic anti tamper cover

    Features

    • 8 Stereo RCA line inputs (internally mono mixed).
    • 2 Microphone XLR inputs with phantom power option.
    • Adjustable line input sensitivity 0.3/0.7V.
    • Individual bass, treble and volume controls of all line inputs.
    • 8 Balanced 3 pin XLR line outputs.
    • Individual volume controls of all 8 outputs.
    • Alert/evacuation/pre chime tone generator included (alert/evac tones comply to AS1670.4) .
    • Emergency balanced input with selectable phantom power and input sensitivity.
    • Programmable labelling of input sources and output zones via USB keyboard.
    • Programme isolate function.
    • Four programmable presets.
    • Tampering lockout feature.
    • Power fail trigger.
    • 240V AC or 24V DC operation.
    • 19” Rack Mount (2 unit).

    Preset Operation
    The Redback A4480B Audio Matrix Switcher features six user presets for easily recalling regularly used configurations. Presets one to four are programmable by the user and can be accessed at any time. Preset five serves as a convenient "last setting" option before a new preset is loaded, allowing for a quick return to a previous system configuration. Preset six serves as a backup of the initial system configuration. Users can select presets from the front panel or remotely by using the A 4476 preset selection wallplate.

    Input and Output Operation
    This system can support 8 zone paging consoles, 8 local zone inputs, 1 emergency paging input, 1 alert/evac input, and 8 auxiliary audio source inputs. Each auxiliary input has a selectable sensitivity range of 0.3 to 0.7V and can be routed to any individual zone or combination of zones. Additionally, each input is equipped with volume, treble, and bass controls, as well as a signal presence indicator. The programmable display clearly shows the selected input and its corresponding outputs.

    The A4475 wallplate allows for remote selection of auxiliary inputs in each zone (maximum one per zone) when connected via Cat 5 cable. This wallplate allows for selecting any auxiliary source and adjusting the local level.

    A 4478 local input wallplate can be added to each zone for connecting local mic or line audio sources. This wallplate is compatible with the A 4475 program selection wallplate.

    Specialized volume controls and signal indicators ensure tamper-proof operation for emergency paging and alert/evac signals. Closing contacts initiate the alert/evac signal.

    Each output is equipped with volume controls and features 3-pin balanced line level XLRs, totaling 8 outputs.

    Program Isolate
    This feature enables the "blocking" of chosen RCA audio inputs to designated zones. This has no impact on paging or tones.

    Priority Muting Operation
    The Redback A4480B is a high-quality audio matrix switcher made in Australia, designed to efficiently handle 8 inputs and 8 outputs. With its priority muting system, this device ensures that appropriate signals are routed to designated zones based on the condition of the system. For instance, in an emergency paging mode, all inputs, including alert and evacuation signals, are muted to allow for live announcements through the paging microphone. In alert/evac mode, all inputs are muted, allowing for tones and recorded messages to be played throughout all zones. This functionality makes the A4480B a reliable choice for any professional audio setup.

    In the zone paging mode, auxiliary signals will be muted when a local input is connected through the optional A4478 wallplate. This prevents interruptions during functions or events and can be prohibited via the front panel's PA on/off function.
