Description
The A2387A is a robust, high-power speaker switcher designed for advanced audio configurations. With a dual-source feature, it enables the connection and operation of two separate amplifiers or receivers, allowing for simultaneous drive of selected speaker pairs, resulting in a more dynamic listening experience. Each speaker pair has its own dedicated input selector, providing precise control over active sources. Additionally, the A2387A includes individual volume controls and on/off switches for each speaker pair, allowing for comprehensive management of audio output levels and speaker engagement. This all-in-one speaker switcher is versatile in handling various speaker impedances of 4Ω or 8Ω, automatically matching them for optimal performance and compatibility. Its unique design with autoformers minimizes signal loss and distortion, perfect for high-fidelity audio systems. The A2387A is ideal for complex audio setups, such as multi-room or multi-zone systems, where seamless integration of multiple audio sources and precise control of speaker outputs are crucial.
Features
- Pluggable screw terminal connections
- 300W total RMS continuous power handling
- Heavy duty transformer based impedance system protects against power loss
- Left and right channels are completely isolated for safe operation with any amplifier
- Quick connect terminals will accomodate 16AWG to 22AWG wire
- Can be connected to two different amplifiers via A/B switch
- Circuit breaker protected
Specifications
- Speaker connections: 4Ω or 8Ω
- Frequency Response: 30Hz ~ 20 kHz ± 2dB
- Max Audio Attenuation: - 33 dB
- Power Handling: 300W RMS Max (total)
- Dimensions: 432L x 152W x 56H mm
- Shipping Weight: 3.66000Kg
