Description
The Powerhouse 24V 200Ah Lithium LiFePO4 Battery M8/F12 is a reliable energy source designed for various applications, including RVs, marine use, and off-grid solar systems. Leveraging advanced lithium iron phosphate (LiFePO4) technology, this high-capacity battery offers an extended lifespan and enhanced safety over traditional options. With Bluetooth compatibility, users can monitor performance and status through a mobile app, providing real-time insights into charging and discharging progress, along with historical data on both iOS and Android devices.
This 25.6V 200Ah lithium battery matches the size of standard 24V SLA batteries while delivering the benefits of lithium technology. LiFePO4 batteries not only last longer than conventional lead-acid models but are also significantly lighter, weighing just half as much. They provide a higher usable life per cycle, ensuring longer run times by maintaining a higher voltage until nearly depleted. Additionally, these batteries retain 80-90% of their charge during storage, which is considerably more than lead-acid batteries can offer.
Equipped with an internal battery management system, the battery ensures safe charging and discharging by protecting against internal short circuits, overheating, and under/over voltage conditions. This battery can be configured in series or parallel; when connected in series, it is crucial that each unit is discharged to the cut-off level before linking them to maintain balanced cells.
Features
- 5 year warranty.
- 200A Discharge BMS
- Bluetooth battery monitoring in-built for use with Android and iOS apps.
- Internal battery management system for safe charging and discharging.
- Replacement for standard lead acid 200Ah batteries (check dimensions)
- Half the weight of traditional lead acid batteries.
- Less discharge when in storage compared with traditional lead acid batteries.
- Longer service life compared to lead acid.
- Longer run time compared to lead acid.
Specifications
- Dimensions: 520L x 269W x 220Hmm
- Overall Weight: 35.8kg
- Terminal Type: M8
- Connection: 24-51.2V in series, no limit in parallel.
- Note: When used in series each battery will need to be discharged to cut off before connecting so that all cells are all balanced.
- Case Material: ABS
- Case IP Rating: IP65
- Certification: CB/CE
- Shipping Class: UN3480, Class 9
Battery Module
- Nominal Voltage: 25.6V
- Capacity: 200Ah
- Charging Voltage: 27.6V max
- Discharging Voltage: 20.8V
- Charging Current: 200A max (Recommended 40A)
- Max Constant Discharge: 200A
About the Bluetooth monitoring App.
Our Powerhouse battery monitoring app is currently in development, however in the mean time customers can utilise the XiaoXiangElectric battery monitor app available on the GooglePlay and Apple App stores
Factory supplied at 30% charge for safety compliance. Must be charged fully before use.
Suitable for recharging with the mains battery charger models listed in the accessories below.
Excessive temperatures over 65ºC can effect the ABS housing. Need to be well ventilated in warm conditions. Not for use in engine bays.
IMPORTANT NOTE: A fixed installation of this battery in a recreational vehicle such as a caravan, camper or 4WD must adhere to Australian Standard AS/NZS 3001:2. We recommend all customers familiarise themselves with the standards requirements before using these batteries in fixed installations of this type. A professional installer should be consulted when a fixed battery installation is required in a recreational vehicle.
